Версия для печатиМультиметр стрелочный M7030 Mastech

Мультиметр стрелочный M7030 Mastech

Артикул: M7030

1/3” 4 Megapixel progressive scan CMOS, 3.6mm fixed lens (6mm optional), 20fps@4M(2688 x 1520), 25/30fps@3M(2304 x 1296), Support H.264&MJPEG dual codec

Статус: Под заказ

Опт1 12 012.00 a i Для частных лиц при разовом заказе на сумму более 50 000 рублей. Для юридических лиц и индивидуальных предпринимателей при разовом заказе на сумму до 300 000 руб.

Опт2 12 012.00 a i При разовом заказе на сумму более 300 000 руб.

Особенности:

1/3” 4 Megapixel progressive scan CMOS
Support H.264&MJPEG dual codec
20fps@4M(2688 x 1520), 25/30fps@3M(2304 x 1296)
Smart Detection supported
WDR(120dB), Day/Night(ICR), 3DNR, AWB, AGC, BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
3.6mm fixed lens (6mm optional)
Max. IR LEDs Length 40m
IP67, PoE

Технические характеристики:

Camera
Image Sensor     1/3” 4 Megapixel progressive scan CMOS
Effective Pixels     2688(H)x1520(V)
Scanning System     Progressive
Electronic Shutter Speed     Auto/Manual, 1/3(4)~1/100000s
Min. Illumination     0. 01Lux/F2.0(Color), 0Lux/F2.0(IR on)
S/N Ratio     More than 50dB
Video Output     N/A

Camera Features
Max. IR LEDs Length     40m
Day/Night     Auto(ICR)/Color/B/W
Backlight Compensation     BLC / HLC / WDR(120 dB)
White Balance     Auto/Sunny/Night/Outdoor/Customized
Gain Control     Auto/Manual
Noise Reduction     3D
Privacy Masking     Up to 4 areas

Lens
Focal Length     3.6mm (6mm optional)
Max Aperture     F2.0(F2.0)
Focus Control     Manual
Angle of View     H:84°(56°)
Lens Type     Fixed lens
Mount Type     Board-in Type

Video
Compression     H.264/H.264B/H.264H/ MJPEG
Resolution     4M(2688×1520)/4M(2560×1440)/3M(2304×1296)/1080P(1920×1080)/720P(1280×720)/D1(704×576/704×480)/CIF(352×288/352×240)
Frame Rate     Main Stream     4M(1~20fps)/3M(1~25/30fps)(WDR OFF)
Sub Stream     D1/CIF(1 ~ 25/30fps)
Third Stream     720P(1-20fps)
Bit Rate     H.264: 32K ~ 10Mbps
Corridor Mode     Support

Audio
Compression N/A
Interface N/A

Smart Function(Optional)
Smart detection Tripwire, Intrusion, Abandoned/Missing, Scene Change, Audio detect, Face detect

Network
Ethernet     RJ-45 (10/100Base-T)
Wi-Fi     N/A
Protocol     IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour,802.1x
Compatibility     ONVIF ,PSIA,CGI
Max. User Access     20 users
Smart Phone            iPhone, iPad, Android, Windows Phone

Auxiliary Interface
Memory Slot     N/A
RS485     N/A
Alarm     N/A
PIR Sensor Range     N/A

General
Power Supply     DC12V, PoE (802.3af)
Power Consumption     < 5W
Working Environment     -30°C~+60°C, Less than 95% RH
Ingress Protection     IP67
Vandal Resistance     N/A
Dimensions     Φ70mm×180mm
Weight     0.4kg
